The SEAF-20-01-L-04-2-RA-GP-TR is a high-density, high-speed edge card socket from Samtec's SEARAY™ family. This connector is designed for applications requiring a right-angle connection and reliable signal integrity in a compact form factor. It is packaged in tape and reel for automated assembly.

Applications:

• High-speed backplanes
• Edge card connections for PCBs
• Data center infrastructure
• Networking and telecommunications equipment
• Medical diagnostic equipment
• Test and measurement devices

Features:

• High-Density Design: Allows for a high number of signals in a small footprint.
• Right-Angle Configuration: Facilitates connections where boards are perpendicular to each other.
• Edge Card Socket: Designed specifically for mating with edge cards.
• SEARAY™ Contact System: Provides high-reliability and signal integrity.
• Tape and Reel Packaging: Suitable for automated pick-and-place assembly.
• Gold Plating (GP): Ensures optimal conductivity and corrosion resistance.

Benefits:

• Increased Board Density: Enables more functionality in a smaller area.
• Reliable Connections: Ensures consistent performance in demanding environments.
• Simplified Assembly: Tape and reel packaging streamlines the manufacturing process.
• High-Speed Performance: Supports high data rates for modern applications.
• Design Flexibility: Right-angle configuration provides options for board layout.

Additional Details:

The SEAF-20-01-L-04-2-RA-GP-TR features a 1.27 mm pitch and is manufactured with high-quality materials for long-term reliability. The gold-plated contacts ensure minimal signal loss and a robust connection. This connector is ideal for high-speed digital systems where board space is limited.

Consult the official Samtec datasheet for detailed dimensions, electrical specifications, and mating information.
