Name: SDL-114-T-12
Brand: Samtec Inc.
SKU: 1292903
Availability: InStock
Rating: 4.85 (5 reviews)

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr	Samtec Inc.
Series	SDL
Package	Tube
Connector Type	Receptacle
Contact Type	Female Socket
Style	Board to Board
Number of Positions	28
Number of Positions Loaded	All
Pitch - Mating	0.100" (2.54mm)
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	30.0µin (0.76µm)
Insulation Color	Black
Insulation Height	0.095" (2.41mm)
Contact Length - Post	0.095" (2.41mm)
Temperature Range - Operating	-55°C ~ 125°C
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Circular
Contact Material	Beryllium Copper
Base Product Number	SDL-114
Other Names	SAM1138-14
Standard Package	1
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	1292903-SDL-114-T-12
Ultra Librarian 3D Model	Ultra Librarian SDL-114-T-12 CAD Model

Description

The Samtec Inc. SDL series connector is a rectangular connector with 28 female socket contacts in a 2-row configuration, designed for board-to-board applications.

Manufacturer: Samtec Inc.
Series: SDL
Type: rectangular connector
Contacts: 28 female socket contacts
Rows: 2-row
Application: board-to-board
Fastening Type: push-pull
Mounting Type: through-hole
Contact Material: beryllium copper
Insulation Material: black liquid crystal polymer (LCP)
Pitch: 0.100" (2.54mm)
Contact Finish: gold
Finish Thickness: 30.0µin (0.76µm) for mating
Voltage Rating: -
Operating Temperature Range: -55°C ~ 125°C
Packaging: tube
