Same model may have multiple batches, images only for reference.
450BXC22MEFC16X20 Rubycon
Same model may have multiple batches, images only for reference.

450BXC22MEFC16X20

Part No 450BXC22MEFC16X20
Manufacturer Rubycon
Catalog Aluminum Capacitors
Description CAP ALUM 22UF 20% 450V RADIAL / 22 µF 450 V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr Rubycon
Series BXC
Package Bulk
Product Status Active
Capacitance 22 µF
Tolerance ±20%
Voltage - Rated 450 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 12000 Hrs @ 105°C
Temperature Range - Operating -25°C ~ 105°C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 304 mA @ 120 Hz
Ripple Current @ High Frequency 760 mA @ 100 kHz
Lead Spacing 0.295" (7.50mm)
Size / Dimension 0.630" Dia (16.00mm)
Height - Seated (Max) 0.866" (22.00mm)
Surface Mount Land Size -
Mounting Type Through Hole
Package / Case Radial, Can
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1357707-450BXC22MEFC16X20
Ultra Librarian 3D Model Ultra Librarian 450BXC22MEFC16X20 CAD Model

Description

The Rubycon BXC series aluminum electrolytic capacitor is a high-quality component designed for general-purpose applications.

  • Capacitance: 22 µF
  • Voltage Rating: 450 V
  • Tolerance: ±20%
  • Mounting Type: Through-Hole
  • Package: Radial, Can
  • Size: 0.630" diameter and a height of 0.866"
  • Lifetime: 12000 hours @ 105°C
  • ESR: Low
  • Ripple Current: 304 mA @ Low Frequency, 760 mA @ High Frequency
  • Active Product: Yes
  • Manufacturer: Rubycon
