Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Number of Characters 2
Size / Dimension 0.748" H x 0.984" W x 0.315" D (19.00mm x 25.00mm x 8.00mm)
Digit/Alpha Size 0.56" (14.30mm)
Display Type 7-Segment
Common Pin Common Cathode
Color Red
Voltage - Forward (Vf) (Typ) 2.05V
Current - Test 10mA
Millicandela Rating 90mcd
Wavelength - Peak 626nm
Power Dissipation (Max) 65mW
Case / Package 18-DIP
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1565263-LB-602AK2
Ultra Librarian 3D Model Ultra Librarian LB-602AK2 CAD Model
