Products specifications

RoHS State Request Verification
Manufacturer Rochester Electronics
Win Source Part Number 1265829-TD8251A
Manufacturer Homepage www.rocelec.com/
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TD8251A CAD Model

Description

The TD8251A is a monolithic audio power amplifier from Rochester Electronics. It is designed for high-quality audio amplification in various applications, particularly those requiring bridge-tied load (BTL) configuration for increased power output. This IC provides a robust and reliable solution for driving speakers in audio systems.

Applications:

  • Car Audio Amplifiers: Powers speakers in car audio systems, providing high power output with BTL configuration.
  • Portable Audio Devices: Amplifies audio signals in portable devices such as boomboxes and personal stereos.
  • Home Audio Systems: Used in home theater systems and stereo amplifiers for driving speakers.
  • Gaming Consoles: Powers speakers in gaming consoles, providing immersive audio experiences.
  • Intercom Systems: Amplifies audio signals in intercom systems for clear and loud communication.

Features:

  • Bridge-Tied Load (BTL) Configuration: Delivers higher power output compared to single-ended amplifiers.
  • Low Distortion: Provides high-quality audio reproduction with minimal distortion.
  • High Output Power: Delivers sufficient power to drive speakers effectively.
  • Built-in Protection Circuits: Protects the amplifier from overvoltage, overcurrent, and thermal overload.
  • Standby Function: Reduces power consumption when the amplifier is not in use.

Benefits:

  • High Power Output: BTL configuration provides increased power to drive speakers effectively.
  • Excellent Audio Quality: Low distortion ensures high-fidelity audio reproduction.
  • Reliable Operation: Built-in protection circuits prevent damage from faults.
  • Reduced Power Consumption: Standby function minimizes power consumption when idle.
  • Simplified Design: Requires few external components, reducing board space and cost.

Additional Details:

The TD8251A typically comes in a multi-lead package. Key specifications include supply voltage range, output power, distortion, and load impedance. The BTL configuration doubles the voltage swing across the load, resulting in four times the power compared to a single-ended amplifier with the same supply voltage. Refer to the Rochester Electronics datasheet for detailed specifications, application circuits, and thermal considerations.
