Same model may have multiple batches, images only for reference.
M38507F8ASP#U1
Same model may have multiple batches, images only for reference.

M38507F8ASP#U1

Part No M38507F8ASP#U1
Manufacturer Rochester Electronics
Catalog Embedded - Microcontrollers
Description IC MCU 8BIT 32KB FLASH 42SDIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Features 740 series Microcontroller IC 8-Bit 12.5MHz 32KB (32K x 8) FLASH 42-SDIP
Manufacturer Renesas Electronics America
Series 740/38000
Package Bulk
Part Status Obsolete
Core Processor 740
Core Size 8-Bit
Speed 12.5MHz
Connectivity SIO, UART/USART
Peripherals PWM, WDT
Number of I/O 32
Program Memory Size 32KB (32K x 8)
Program Memory Type FLASH
Supply Voltage 1.8V ~ 5.5V
Data Converters A/D 9x10b
Oscillator Type Internal
Operating Temperature Range -20°C ~ 85°C (TA)
Mounting Through Hole
Package 42-SDIP (0.600", 15.24mm)
Case / Package 42-SDIP
ECCN EAR99
HTSUS 8542.31.0001
Quantity per package 1
Popularity High
Supply and Demand Status Balance
Win Source Part Number 924839-M38507F8ASP#U1
Ultra Librarian 3D Model Ultra Librarian M38507F8ASP#U1 CAD Model

Description

The Renesas Electronics America M38507F8ASP#U1 is an 8-bit microcontroller IC that belongs to the 740/38000 series.

  • Series: 740/38000
  • Speed: 12.5MHz
  • Program Memory Size: 32KB (32K x 8)
  • Product Status: Obsolete
  • Popularity: High
  • Number of I/Os: 32
  • Connectivity: SIO, UART/USART
  • Peripherals: PWM, WDT
  • Operating Temperature: -20°C ~ 85°C (TA)
  • Mounting Type: Through Hole
  • Package Size: 42-SDIP (0.600", 15.24mm)
