PX1002 RF Monolithics, Inc
Same model may have multiple batches, images only for reference.

PX1002

Part No PX1002
Manufacturer RF Monolithics, Inc
Catalog SAW Filters
Description FILTER,PX,86.850 MHZ,
Datasheet
PX1002 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters - SAW Filters
Mfr RF Monolithics, Inc
Package Tape & Reel (TR)Tape & Reel (TR)Bag
Product Status Active
Frequency - Center 86.85MHz
Bandwidth 50kHz
Insertion Loss 3dB
Ratings AEC-Q200
Applications Cellular, TDMA, IF
Mounting Type Surface Mount
Package / Case 12-SMD, No Lead
Height (Max) 0.079" (2.00mm)
Size / Dimension 0.524" L x 0.256" W (13.31mm x 6.50mm)
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.60.0060
Win Source Part Number 658273-PX1002
Ultra Librarian 3D Model Ultra Librarian PX1002 CAD Model

Description

The 658273-PX1002 is a SAW filter designed for use in cellular and TDMA applications.

  • Application: cellular and TDMA
  • Center Frequency: 86.85MHz
  • Bandwidth: 50kHz
  • Insertion Loss: 3dB
  • Mounting Type: surface mount
  • Package: 12-SMD
  • Height: 0.079 inches
  • Package: tape and reel
  • AEC-Q200 Rated: yes
  • Standard Package: 3,000 pieces
  • Manufacturer: RF Monolithics, Inc.
  • Product Status: active
