ACS724LLCTR-05AB-T Allegro MicroSystems, LLC ACS724LLCTR-05AB-T real image21487 ACS724LLCTR-05AB-T real image21488 ACS724LLCTR-05AB-T Real Image
Same model may have multiple batches, images only for reference.
ACS724LLCTR-05AB-T Allegro MicroSystems, LLC ACS724LLCTR-05AB-T real image21487 ACS724LLCTR-05AB-T real image21488 ACS724LLCTR-05AB-T Real Image
ACS724LLCTR-05AB-T Allegro MicroSystems, LLC ACS724LLCTR-05AB-T real image21487 ACS724LLCTR-05AB-T real image21488 ACS724LLCTR-05AB-T Real Image
Same model may have multiple batches, images only for reference.

ACS724LLCTR-05AB-T

Part No ACS724LLCTR-05AB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL
Datasheet
ACS724LLCTR-05AB-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel package
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 5A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 400mV/A
Frequency DC ~ 120kHz
Linearity ±1.5%
Accuracy ±0.6%
Operating Supply Voltage 4.5 V ~ 5.5 V
Response Time 4μs
Maximum Supply Current 14mA
Operating Temperature Range -40°C ~ 150°C
Polarization Bidirectional
Mounting SMD
Package 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 766987-ACS724LLCTR-05AB-T
Popularity Medium
Supply and Demand Status Limited
Family Name ACS724LLCTR-05AB-T
ECCN EAR99
Country of Origin Philippines
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian ACS724LLCTR-05AB-T CAD Model

Description

The Allegro MicroSystems ACS724LLCTR-05AB-T is a Hall Effect sensor designed for measuring AC/DC current.

  • Polarization: Bidirectional
  • Input Voltage: 4.5 V to 5.5 V
  • Package: 8-SOIC (0.154", 3.90mm Width)
  • Operating Temperature: -40°C to 150°C
  • Response Time: 4µs
  • Sensitivity: 400mV/A
