RF2607 Real Image
Same model may have multiple batches, images only for reference.

RF2607

Part No RF2607
Manufacturer RF Micro Devices
Catalog Coaxial Connectors (RF)
Description CONN BNC RCPT STR 75OHM EDGE MNT
Datasheet
RF2607 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Amphenol RF Division
Packaging Bulk
Status Active
Connector Style BNC
Connector Type Receptacle, Female Socket
Contact Termination Solder
Shield Termination Solder
Impedance 75 Ohm
Mounting Board Edge, End Launch; Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Fastening Type Bayonet Lock
Maximum Input Frequency 12GHz
Housing Color Silver
Includes 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
Body Material Brass
Body Finish Nickel
Center Contact Plating Gold
Dielectric Material Polytetrafluoroethylene (PTFE)
Temperature Range - Operating -65°C to 165°C
Center Contact Material Beryllium Copper
Mating Cycles 500
Win Source Part Number 293418-RF2607
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RF2607 CAD Model

Description

The Amphenol RF Division 293418-RF2607 is a female socket receptacle that has a bayonet lock fastening type.

  • Impedance: 75-ohm
  • Maximum Input Frequency: 12GHz
  • Connector Style: BNC
  • Mounting Feature: bulkhead-front side nut
  • Manufacturer: Amphenol RF Division
  • Popularity: medium
  • Supply and Demand Status: limited
  • Perfect for: applications that require a reliable and high-quality connection.
