RF2436TR7

Name: RF2436TR7
Brand: RF Micro Devices
SKU: 293373
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

Part No	RF2436TR7
Manufacturer	RF Micro Devices
Catalog	RF Switches
Description	IC TXRX SW GAAS MESFET SOT23-5
Datasheet	RF2436TR7 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	RF/IF and RFID
Manufacturer	RF Micro Devices
Packaging	Reel - TR
Status	Active
Frequency - Lower	DC
Frequency - Upper	2.5GHz
Isolation @ Frequency	24dB @ 900MHz (typ)
Insertion Loss @ Frequency	1dB @ 900MHz
IIP3	39dBm (typ) OIP3
Topology	Reflective
Circuit	SPDT
P1dB	27dBm (typ) OP1dB
Features	Single Line Control
Impedance	50 Ohm
Temperature Range - Operating	-40°C to 85°C
Supply Voltage - Operating	1.5 V to 6 V
RF Type	General Purpose
Case / Package	SOT-5
Win Source Part Number	042316-RF2436TR7
Popularity	Medium
Supply and Demand Status	Balance
Quantity per package	2,500
Ultra Librarian 3D Model	Ultra Librarian RF2436TR7 CAD Model

Description

The RF Micro Devices RF2436TR7 is a reflective SPDT switch with a frequency range of DC to 2.5GHz.

Impedance: 50 Ohm
Control: single line control
Isolation @ 900MHz: 24dB
Insertion Loss @ 900MHz: 1dB
IIP3: 39dBm
P1dB: 27dBm
Application: general purpose RF applications
Package: SOT-5
Temperature Range: -40°C to 85°C
Supply Voltage: 1.5V to 6V
Packaging: reel-tr packaging with a quantity of 2,500 per package
