TOP234YN Real Image TOP234YN real image7769
Same model may have multiple batches, images only for reference.
TOP234YN Real Image TOP234YN real image7769
TOP234YN Real Image TOP234YN real image7769
Same model may have multiple batches, images only for reference.

TOP234YN

Part No TOP234YN
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT OVP UVLO TO220
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube/Rail
Status Not For New Designs
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Flyback
Duty Cycle 78%
Frequency - Switching 66kHz to 132kHz
Power (Watts) 75W
Fault Protection Current Limiting, Over Temperature, Over Voltage
Control Features Frequency Control
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package TO-220-7B
Mounting Through Hole
Win Source Part Number 033364-TOP234YN
Family Name TOP234
Introduction Date August 20, 2001
ECCN EAR99
Halogen Free Not Compliant
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TOP234YN CAD Model

Description

The Power Integrations TOP234YN is an integrated circuit designed for flyback power supply applications.

  • Power Rating: 75W
  • Internally Switched: Internally switched
  • Isolated: isolated
  • Breakdown Voltage: 700V
  • Frequency Range: 66kHz to 132kHz
  • Duty Cycle: 78%
  • Fault Protection: current limiting, over temperature and over voltage
  • Frequency Control: frequency control
  • Part of Family: TOP234 family
  • Package: TO-220-7B package
  • Popularity: common-used part with high popularity in the market
  • Estimated EOL date: 2019
