QH08TZ600 Power Integrations
Same model may have multiple batches, images only for reference.

QH08TZ600

Part No QH08TZ600
Manufacturer Power Integrations
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 600V 8A TO220AC / Diode 600 V 8A Through Hole TO-220AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Power Integrations
Series Qspeed™
Package Tube
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 600 V
Current - Average Rectified (Io) 8A
Voltage - Forward (Vf) (Max) @ If 3.15 V @ 8 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 11.1 ns
Current - Reverse Leakage @ Vr 250 µA @ 600 V
Capacitance @ Vr, F 25pF @ 10V, 1MHz
Mounting Type Through Hole
Package / Case TO-220-2
Supplier Device Package TO-220AC
Operating Temperature - Junction 150°C (Max)
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 658551-QH08TZ600
Ultra Librarian 3D Model Ultra Librarian QH08TZ600 CAD Model

Description

The 658551-QH08TZ600 is a fast recovery diode designed for rectifier applications.

  • Series: Qspeed™
  • Maximum DC Reverse Voltage: 600V
  • Average Rectified Current: 8A
  • Forward Voltage Drop @ 8A: 3.15V
  • Reverse Recovery Time: 11.1ns
  • Reverse Leakage Current @ 600V: 250µA
  • Capacitance @ 10V and 1MHz: 25pF
  • Package: TO-220-2
  • Mounting: Through-hole
  • Temperature Range: Up to 150°C
