LNK306GN-TL Power Integrations LNK306GN-TL Real Image LNK306GN-TL real image1859
Same model may have multiple batches, images only for reference.
LNK306GN-TL Power Integrations LNK306GN-TL Real Image LNK306GN-TL real image1859
LNK306GN-TL Power Integrations LNK306GN-TL Real Image LNK306GN-TL real image1859
Same model may have multiple batches, images only for reference.

LNK306GN-TL

Part No LNK306GN-TL
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT OCP 8SMD
Datasheet
LNK306GN-TL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Reel - TR
Status Active
Output Isolation Non-Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Buck, Buck-Boost, Flyback
Duty Cycle 69%
Frequency - Switching 66kHz
Fault Protection Current Limiting, Open Loop, Over Temperature, Short Circuit
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package SMD-8B
Mounting Surface Mount
Win Source Part Number 019721-LNK306GN-TL
Family Name LNK306
Introduction Date September 02, 2004
ECCN EAR99
Country of Origin China
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian LNK306GN-TL CAD Model

Description

The Power Integrations product with Win Source Part Number 019721-LNK306GN-TL is a non-isolated integrated circuit (IC) with an output voltage of 700V.

  • Topology: buck, buck-boost, and flyback
  • Duty Cycle: 69%
  • Frequency Switching: 66kHz
  • Fault Protection Features: current limiting, open loop, over temperature, and short circuit
  • Category: Integrated Circuits
  • Popularity: high
  • Introduction Date: September 02, 2004
  • Estimated EOL Date: 2022
  • Other Specifications: not provided
