The PLL701-25SC-A0-L, manufactured by PhaseLink Corporation, is a high-performance, low-jitter clock generator and synthesizer. This device is designed to provide precise timing signals for a variety of applications, leveraging advanced Phase-Locked Loop (PLL) technology to achieve exceptional frequency stability and minimal phase noise.

Applications

• High-speed data communication systems: Used in applications such as Ethernet switches and routers.
• Optical networking equipment: Provides timing for transceivers and line cards.
• Test and measurement equipment: Ensures accurate timing for signal generators and analyzers.
• Broadcast video systems: Used in video servers and encoders/decoders.
• High-performance computing: Provides stable clock signals for processors and memory interfaces.

Features

• Low phase noise: Minimizes timing jitter for improved system performance.
• Wide frequency range: Supports a variety of output frequencies.
• Precise frequency synthesis: Offers accurate and stable frequency generation.
• Integrated voltage controlled oscillator (VCO): Simplifies design and reduces external component count.
• Low power consumption: Enables energy-efficient system designs.

Benefits

• Improved system performance: Low jitter and precise timing lead to enhanced data throughput and reduced error rates.
• Simplified design: Integrated VCO reduces the need for external components.
• Reduced development time: Easy to integrate and configure.
• Lower system cost: Integrated features reduce the bill of materials.
• High reliability: Designed for stable and reliable operation in demanding environments.

Additional Details

The PLL701-25SC-A0-L typically operates from a 3.3V power supply. It is available in a compact surface-mount package, making it suitable for high-density board layouts. The device features programmable output dividers, allowing for flexible frequency selection. Its low additive jitter ensures that the generated clock signals maintain high integrity, crucial for sensitive applications. The specific output frequency for the -25SC variant is 25 MHz. The device also incorporates advanced power management features to minimize power consumption during periods of inactivity. Detailed specifications regarding phase noise, frequency stability, and operating temperature range are available in the product datasheet.
