BAV99W Real Image BAV99W real image17589 BAV99W Real Image
Same model may have multiple batches, images only for reference.
BAV99W Real Image BAV99W real image17589 BAV99W Real Image
BAV99W Real Image BAV99W real image17589 BAV99W Real Image
Same model may have multiple batches, images only for reference.

BAV99W

Part No BAV99W
Manufacturer Panjit
Catalog Diodes, Rectifiers - Arrays
Description SURFACE MOUNT SWITCHING DIODES
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Panjit
Win Source Part Number 1151736-BAV99W
Manufacturer Homepage www.panjit.com.tw
Family Name BAV99W
Introduction Date February 21, 2003
ECCN EAR99
Country of Origin Malaysia, Republic of Korea
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Package Bulk
Product Status Obsolete
Diode Configuration 1 Pair Series Connection
Technology Standard
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) (per Diode) 150mA
Voltage - Forward (Vf) (Max) @ If 1.25V @ 150mA
Speed Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr) 4ns
Current - Reverse Leakage @ Vr 2.5µA @ 75V
Operating Temperature - Junction 150°C
Grade -
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Supplier Device Package SOT-323
Ultra Librarian 3D Model Ultra Librarian BAV99W CAD Model

Description

The Panjit BAV99W is a common-used part in the electronic components industry.

  • Popularity: This diode has a high popularity rating and is widely used in various electronic circuits.
  • Features: The BAV99W is a dual diode with a forward voltage of 0.715V and a reverse voltage of 75V.
  • Operating Temperature: The diode is designed to operate @ a maximum temperature of 150°C.
  • Manufacturer and Location: The BAV99W is manufactured by Panjit in Malaysia and the Republic of Korea.
  • EOL Date: The estimated EOL date for this diode is obsolete.
  • Supply and Demand: The supply and demand status for this diode is sufficient.
