ST2-DC48V Real Image
Same model may have multiple batches, images only for reference.

ST2-DC48V

Part No ST2-DC48V
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description IC DRIVABLE PC BOARD RELAY FOR FIELD LOAD SWITCHING | RELAY GEN PURPOSE DPST 8A 48V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Packaging Tube
Status Obsolete
Mounting Style Through Hole
Coil Voltage 48VDC
Contact Form DPST-NO (2 Form A)
Contact Rating (Current) 8A
Switching Voltage 380VAC, 250VDC - Max
Coil Current 5.3mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Fully
Must Operate Voltage 38.4 VDC
Must Release Voltage 4.8 VDC
Operate Time 15ms
Release Time 10ms
Temperature Range - Operating -40°C ~ 60°C
Contact Material Silver Alloy
Relay Type General Purpose
Coil Resistance 9 kOhms
Manufacturer Pack Quantity 50
MSL Level Not Applicable
Win Source Part Number 1260237-ST2-DC48V
Manufacturer Homepage 0
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ST2-DC48V CAD Model

Description

The Panasonic Electric Works ST2-DC48V is a general-purpose relay that is designed for use in a variety of applications.

  • Category: Relays
  • Manufacturer: Panasonic Electric Works
  • Contact Form: DPST-NO (2 Form A)
  • Contact Material: Silver alloy
  • Coil Voltage: 48VDC
  • Coil Current: 5.3mA
  • Switching Voltage: 380VAC, 250VDC - Max
  • Seal Rating: Fully sealed
  • Temperature Range: -40°C ~ 60°C
  • Product Status: Obsolete
