PA1AS-24V Panasonic
Same model may have multiple batches, images only for reference.

PA1AS-24V

Part No PA1AS-24V
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays
Family Power Relays, Over 2 Amps
Manufacturer Panasonic-Electric-Works
Series PA
Packaging Tube
Relay Type General Purpose
Coil Type Non Latching
Coil Current 7.5mA
Coil Voltage 24VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 5A
Switching Voltage 250VAC, 110VDC - Max
Turn On Voltage (Max) 16.8 VDC
Turn Off Voltage (Min) 1.2 VDC
Operate Time 10ms
Release Time 5ms
Features Sealed - Fully
Mounting Style Through Hole
Termination Style PC Pin
Contact Material Silver Nickel (AgNi)
Coil Power 180 mW
Coil Resistance 3.2 kOhms
Operating Temperature Range -40°C ~ 70°C
Win Source Part Number 209620-PA1AS-24V
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PA1AS-24V CAD Model

Description

The Panasonic-Electric-Works is a general-purpose relay with a Win Source Part Number of 209620-PA1AS-24V.

  • Win Source Part Number: 209620-PA1AS-24V
  • Family: Power Relays, Over 2 Amps
  • Series: PA
  • Package: Tube
  • Termination Style: PC Pin
  • Mounting Style: Through-Hole
  • Operating Temperature: -40°C ~ 70°C
  • Design: Sealed Fully
  • Contact Form: SPST-NO (1 Form A)
  • Contact Material: Silver Nickel (AgNi)
  • Coil Resistance: 3.2 kOhms
  • Coil Current: 7.5mA
  • Operate Time: 10ms
  • Relay Type: Non-Latching
  • Coil Voltage: 24VDC
  • Contact Rating (Current): 5A
  • Switching Voltage: 250VAC, 110VDC - Max
  • Turn-On Voltage (Max): 16.8 VDC
  • Turn-Off Voltage (Min): 1.2 VDC
  • Release Time: 5ms
  • Coil Power: 180 mW
