HC1E-HTM-AC12V-F Real Image
Same model may have multiple batches, images only for reference.

HC1E-HTM-AC12V-F

Part No HC1E-HTM-AC12V-F
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPDT 5A 12V
Datasheet
HC1E-HTM-AC12V-F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Packaging Bulk
Status Active
Relay Type General Purpose
Coil Type Non Latching
Coil Current 100mA
Coil Voltage 12VAC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 5A
Switching Voltage 250VAC - Max
Turn On Voltage (Max) 9.6 VAC
Turn Off Voltage (Min) 3.6 VAC
Operate Time 10ms
Release Time 10ms
Features Sealed - Amber
Mounting Chassis Mount
Termination Style Plug In
Coil Power 1.2 VA
Temperature Range - Operating -40°C to 60°C
Win Source Part Number 001483-HC1E-HTM-AC12V-F
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian HC1E-HTM-AC12V-F CAD Model

Description

The HC1E-HTM-AC12V-F is a high-performance relay designed and manufactured by Panasonic Electric Works. This relay is widely used in the electronics industry and is a reliable and cost-effective solution for high-performance electronic circuits. The supply and demand status is limited, making it slightly less easily available. It is a general-purpose relay and is suitable for use in a variety of applications. It is a high-quality and durable solution for electronic circuits.
