EXC-14CP121U Panasonic – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

EXC-14CP121U

Part No EXC-14CP121U
Manufacturer Panasonic
Catalog Common Mode Chokes
Description CMC 300MA 2LN 120 OHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 120 Ohms @ 100 MHz
Current Rating (Max) 300mA
DC Resistance (DCR) (Max) 500mOhm
Voltage Rating - DC 5V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Size / Dimension 0.033" L x 0.026" W (0.85mm x 0.65mm)
Height (Max) 0.020" (0.50mm)
Case / Package 0302 (0806 Metric)
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1527579-EXC-14CP121U
Ultra Librarian 3D Model Ultra Librarian EXC-14CP121U CAD Model
