Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 500mA
Voltage - Forward (Vf) (Max) @ If 550mV @ 500mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 3.6ns
Current - Reverse Leakage @ Vr 100μA @ 35V
Capacitance @ Vr, F 10.5pF @ 10V, 1MHz
Mounting SMD (SMT)
Case / Package SMini2-F5-B
Operating Temperature - Junction 125°C (Max)
Win Source Part Number 013810-DB2J40700L
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Family Name DB2J407
Introduction Date October 15, 2009
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian DB2J40700L CAD Model

Description

DB2J40700L - General Purpose Diode

The DB2J40700L is a versatile general-purpose diode with excellent performance characteristics ideal for a wide range of electronic applications. It is engineered to offer reliable operation in various environmental conditions, making it suitable for both consumer electronics and industrial systems.

  • Signal processing in communication devices
  • Protection circuits in electronic devices
  • Power rectification in power management systems
  • Current steering in logic circuits

Features and Benefits

  • Wide operating temperature range, ensuring reliability across conditions
  • Stable forward voltage drop, minimizing energy loss
  • SMD packaging for easy integration into PCB designs
  • High durability for long-lasting performance

The DB2J40700L combines durability and performance in one package, making it a dependable choice for engineers and product designers looking for a reliable general-purpose diode.
