Categories Discrete Semiconductor Products
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 80V
Current - Average Rectified (Io) 100mA (DC)
Voltage - Forward (Vf) (Max) @ If 1.2V @ 100mA
Reverse Recovery Time (trr) 3ns
Current - Reverse Leakage @ Vr 100nA @ 75V
Capacitance @ Vr, F 1.2pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package SSMini2-F5-B
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 013581-DA2S10100L
Family Name DA2S101
Introduction Date December 02, 2009
ECCN EAR99
Halogen Free Unknown
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian DA2S10100L CAD Model

Description

DA2S10100L Overview

The DA2S10100L is a high-efficiency semiconductor diode specifically designed for fast switching applications. It offers a maximum reverse voltage of 100V and a forward current capacity of 10A, ensuring robust performance in demanding environments.

Key Features and Benefits

  • High efficiency with low forward voltage drop.
  • Fast recovery time suitable for high-frequency applications.
  • Compact and reliable design for enhanced performance.

Applications and Projects

  • Power supply circuits.
  • Switch-mode power supplies (SMPS).
  • DC-DC Converters.
  • Motor drives.

Additional Details

This diode is ideal for engineers looking to optimize their power management systems, offering both efficiency and reliability across various industrial applications.
