AQY211EH Real Image AQY211EH Real Image
Same model may have multiple batches, images only for reference.
AQY211EH Real Image AQY211EH Real Image
AQY211EH Real Image AQY211EH Real Image
Same model may have multiple batches, images only for reference.

AQY211EH

Part No AQY211EH
Manufacturer Panasonic
Catalog Solid State Relays
Description SSR RELAY SPST-NO 1A 0-30V / Solid State SPST-NO (1 Form A) 4-DIP (0.300", 7.62mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Panasonic
Series PhotoMOS™ AQY
Package Tube
Product Status Active
Mounting Type Through Hole
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.14VDC
Voltage - Load 0 V ~ 30 V
Load Current 1 A
On-State Resistance (Max) 500 mOhms
Termination Style PC Pin
Package / Case 4-DIP (0.300", 7.62mm)
Supplier Device Package 4-DIP
Base Product Number AQY211
Standard Package 100 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 564443-AQY211EH
Ultra Librarian 3D Model Ultra Librarian AQY211EH CAD Model

Description

The Panasonic 564443-AQY211EH is a solid-state relay from the PhotoMOS AQY series. It is a through-hole device with a PC pin termination style.

  • Series: PhotoMOS AQY
  • Mounting Type: Through-Hole
  • Termination Style: PC Pin
  • Circuit Configuration: SPST-NO (1 Form A)
  • Load Current: Up to 1 A
  • Input Voltage: 1.14VDC
  • Switching Signal: AC and DC
  • Maximum On-State Resistance: 500 mOhms
  • Load Voltage Range: 0 V to 30 V
  • Package: 4-DIP
  • Pitch: 0.300" (7.62mm)
  • Product Status: Active
  • Manufacturer: Panasonic
