Products specifications

Category Connectors, Interconnects - Backplane Connectors - DIN 41612
Mfr Oupiin
Series 9001
Package Tray
Product Status Active
Connector Type Receptacle, Female Sockets
Number of Positions 20
Number of Positions Loaded All
Pitch 0.100" (2.54mm)
Number of Rows 2
Style B/2 (1/2 B)
Mounting Type Through Hole
Termination Solder
Contact Finish Gold
Contact Finish Thickness Flash
Temperature Range - Operating -55°C ~ 125°C
Current Rating (Amps) 2A
Material Flammability Rating UL94 V-0
Material - Insulation Polyester Thermoplastic, Glass Filled
Base Product Number 9001
Standard Package 216 pcs
MSL Level 2 (1 Year)
HTSUS 8536.69.4040
Win Source Part Number 858565-9001-36201C00A
Ultra Librarian 3D Model Ultra Librarian 9001-36201C00A CAD Model

Description

The 9001-36201C00A is a 20-position DIN 41612 backplane connector from Oupiin.

  • Series: 9001
  • Pitch: 0.100" (2.54mm)
  • Connector Type: Receptacle with Female Sockets
  • Positions Loaded: All 20
  • Rows: 2
  • Termination Style: Solder
  • Contact Finish: Gold with Flash Thickness
  • Insulation Material: Polyester Thermoplastic, Glass Filled
  • Flammability Rating: UL94 V-0
  • Package: Tray
  • Current Rating: 2A
  • Mounting: Through-Hole
  • Temperature Range: -55°C to 125°C
