The ON Semiconductor SMS05T1G is a state-of-the-art surge protection device designed to safeguard sensitive electronic circuits from transient voltage spikes and surges. This compact and robust component is an ideal choice for a wide range of applications, including data lines, USB interfaces, and other communication ports susceptible to electrostatic discharge (ESD) and other voltage-induced damages.

Key Features

• Transient Protection: The SMS05T1G offers excellent transient protection for five lines, with a peak pulse power of 200 Watts (8/20μs waveform) per line, ensuring your devices remain safe from sudden surges.
• Low Clamping Voltage: It features a low clamping voltage, which activates swiftly upon detecting a surge, thereby limiting the exposure of the protected component to harmful voltages.
• Low Leakage Current: With its low leakage current, this device ensures minimal power loss when in standby mode, making it energy-efficient and ideal for battery-powered applications.
• Fast Response Time: The SMS05T1G responds to over-voltage events in picoseconds, providing immediate protection against transient voltages.
• ESD Protection: It is capable of withstanding ESD strikes at ±30kV (air and contact discharge), according to the IEC 61000-4-2 standard, offering a high level of protection for sensitive electronics.

Applications

The versatility of the SMS05T1G makes it suitable for a variety of applications where voltage spikes can be detrimental to electronic equipment. It is commonly used in:

• Portable Electronics
• Computer Peripherals
• Network Devices
• Telecommunication Systems
• Industrial Controls

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the SMS05T1G is no exception. It is manufactured in ISO-certified facilities, ensuring high standards of production. The device is also RoHS compliant, meaning it meets the restrictions on the use of certain hazardous substances in electrical and electronic equipment.

With its robust design and superior protection capabilities, the ON Semiconductor SMS05T1G is an excellent choice for safeguarding your electronic investments against the unpredictable nature of transient voltages.
