Products specifications

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr ON Semiconductor
Series *
Package Bulk
Product Status Active
Base Product Number SBS006
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 314221-SBS006-TL-E
Ultra Librarian 3D Model Ultra Librarian SBS006-TL-E CAD Model

Description

The SBS006-TL-E from ON Semiconductor is a state-of-the-art Schottky Barrier Diode designed for high-efficiency power management applications. This compact and robust diode is engineered to provide low forward voltage drop and significant power reduction, making it an ideal choice for a wide range of electronic devices.

Key Features

  • Low Forward Voltage Drop (VF): The SBS006-TL-E boasts a low VF, which enhances overall system efficiency by minimizing power loss during conduction.
  • High Current Capability: With its ability to handle high current levels, this diode is suitable for demanding applications that require robust power handling.
  • Low Power Loss: The device's optimized design results in reduced power loss, which is crucial for energy-sensitive circuits.
  • Small Package Size: The SBS006-TL-E comes in a small SOD-323 package, making it an excellent choice for space-constrained applications.
  • High Reliability: Manufactured by ON Semiconductor, a leader in semiconductor solutions, the SBS006-TL-E is built to meet high reliability standards, ensuring long-term performance.

Applications

The SBS006-TL-E is versatile and can be used in various applications, including but not limited to:

  • Power supply rectification
  • DC-DC converters
  • Free-wheeling diodes in power switches
  • Reverse battery protection
  • Portable devices and battery-powered equipment

Technical Specifications

Parameter Value Package SOD-323 Maximum Forward Voltage 0.5V at 10mA Maximum Reverse Current 200µA at 20V Operating Temperature Range -55°C to +125°C

In summary, the SBS006-TL-E from ON Semiconductor is a highly efficient, reliable, and compact Schottky Barrier Diode that meets the needs of modern electronic designs requiring high-performance power management solutions.
