The NGTB20N135IHRWG is a high-performance insulated gate bipolar transistor (IGBT) developed by ON Semiconductor, a leading provider of semiconductor-based solutions. This IGBT is designed to deliver exceptional efficiency and power control for a wide range of applications, including motor drives, uninterruptible power supplies (UPS), inverters, and other energy-efficient systems.

Key Features

• High Current Capability: The NGTB20N135IHRWG is capable of handling continuous collector currents up to 40A at 25°C, making it suitable for high-power applications.
• High Voltage Rating: With a collector-emitter voltage (Vce) rating of 1350V, this IGBT can efficiently manage high voltage operations, providing robust performance in demanding environments.
• Low On-Resistance: The device features a low on-state voltage drop due to its optimized saturation voltage, resulting in reduced conduction losses and improved overall efficiency.
• Fast Switching Speed: The fast switching characteristics of the NGTB20N135IHRWG minimize switching losses and enhance performance in high-frequency applications.
• Co-Packaged Free-Wheeling Diode: This IGBT comes with an integrated fast recovery diode, which provides protection against reverse voltage transients and reduces component count in circuit designs.

Applications

The NGTB20N135IHRWG IGBT is ideal for a variety of applications that require high efficiency and power density. Its robustness and reliability make it a preferred choice for:

• Motor Drives
• Power Inverters
• Power Factor Correction (PFC) Circuits
• Switched Mode Power Supplies (SMPS)
• Renewable Energy Systems
• Welding Equipment

Quality and Reliability

ON Semiconductor's commitment to quality and reliability is evident in the NGTB20N135IHRWG. The device is manufactured using state-of-the-art technology and is subjected to rigorous testing to ensure high performance and durability in the field. With its advanced features and proven reliability, the NGTB20N135IHRWG is an excellent choice for designers looking to enhance the efficiency and longevity of their power management systems.
