Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) (per Diode) 8A
Voltage - Forward (Vf) (Max) @ If 1.5V @ 8A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 60ns
Current - Reverse Leakage @ Vr 10μA @ 600V
Operating Temperature - Junction -65°C to 175°C
Mounting Through Hole
Case / Package TO-220AB
Win Source Part Number 091949-MUR1660CTG
Family Name MUR1660CT
Introduction Date November 21, 2000
ECCN EAR99
Country of Origin China, Vietnam
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MUR1660CTG CAD Model

Description

ON Semiconductor MUR1660CTG Ultra-Fast Recovery Rectifier

The ON Semiconductor MUR1660CTG is a state-of-the-art ultra-fast recovery rectifier designed to meet the demanding requirements of high-efficiency power supply systems. This component is a perfect choice for applications that require rapid switching and low power loss. The MUR1660CTG is housed in a TO-220AB package, which ensures robustness and ease of mounting in various circuit configurations.

Key Features

  • Voltage Ratings: With a repetitive peak reverse voltage (VRRM) of 600V, the MUR1660CTG is well-suited for high-voltage applications.
  • High Current Capability: This rectifier can handle a forward current (IF(AV)) of 16A, making it capable of supporting high current demands.
  • Ultra-Fast Recovery Time: With a recovery time (trr) typically less than 60ns, the MUR1660CTG minimizes power loss and improves efficiency in fast-switching applications.
  • Low Forward Voltage Drop: The low forward voltage (VF) reduces conduction losses and helps to maintain efficiency in power conversion systems.
  • High Surge Current Capacity: It can withstand a surge current (IFSM) of 150A, which is essential for handling high transient loads.

Applications

The MUR1660CTG is ideal for use in a variety of power applications including:

  • Switch-mode power supplies (SMPS)
  • Power factor correction (PFC) circuits
  • Freewheeling diodes in converters and motor control circuits
  • Snubber diodes
  • Automotive environment applications

Product Quality and Reliability

ON Semiconductor is known for its commitment to quality and the MUR1660CTG is no exception. It is designed to meet the stringent requirements of the industrial and automotive market. The device is also RoHS compliant, ensuring that it meets current environmental standards for hazardous substances.

With its combination of high voltage rating, high current capability, ultra-fast recovery time, and low forward voltage drop, the MUR1660CTG from ON Semiconductor is an excellent choice for designers looking to optimize the performance and efficiency of their power conversion systems.
