The MC74VHC1GT14DFT1 is a high-speed CMOS device from ON Semiconductor designed to operate as a single Schmitt-trigger inverter. This integrated circuit is a part of the VHC family, which is known for its low power consumption and high noise immunity equivalent to that of the LSTTL family of products.

Key Features

• Advanced CMOS Technology: The MC74VHC1GT14DFT1 utilizes advanced silicon-gate CMOS technology to achieve high-speed operation similar to LSTTL combined with the low power consumption of standard CMOS integrated circuits.
• High Noise Immunity: The device boasts a noise immunity characteristic of 28% VCC minimum, providing stable operation in noisy environments.
• Power Down Protection: Inputs and outputs are designed to withstand −65 to +7.0V with respect to VCC when powered down, ensuring the device is protected during installation or when power is off.
• Low Power Dissipation: With a low power dissipation of 2µW typical at 25°C, the MC74VHC1GT14DFT1 is an energy-efficient option for modern electronic applications.
• High-Speed Operation: The device supports high-speed operation, with a propagation delay time of 8.3ns at VCC = 5V, CL = 15pF, TA = 25°C.

Applications

The versatility of the MC74VHC1GT14DFT1 makes it suitable for a wide range of applications, including:

• Wave shaping and noise filtering
• Digital signal processing
• Square wave and pulse generation
• Logic level conversion for interfacing different voltage levels within a system

Package and Quality

The MC74VHC1GT14DFT1 comes in a space-saving SC-70 package, which is ideal for applications where board space is at a premium. ON Semiconductor is committed to providing high-quality products, and this device is no exception, meeting stringent quality standards for reliability and performance.
