ON Semiconductor MC14013BCP Dual Type D Flip-Flop IC

The ON Semiconductor MC14013BCP is a versatile and robust integrated circuit that serves as a dual type D flip-flop. This component is a fundamental building block in digital electronics, providing reliable bistable state storage functionality. The flip-flop is edge-triggered, capturing the value of the input data at the moment of the rising edge of the clock signal and holding this value until the next triggering event.

Constructed with MOS P-Channel and N-Channel enhancement mode devices in a single monolithic structure, the MC14013BCP offers high-speed performance combined with low power consumption. This makes it an excellent choice for a wide range of applications, including control systems, data storage, frequency dividers, and shift registers, among others.

The device is encapsulated in a DIP-14 (Dual In-line Package) format, which allows for easy integration into both prototyping breadboards and final product PCBs (Printed Circuit Boards). Each flip-flop has independent Data (D), Set (S), Reset (R), and Clock (CLK) inputs, with Q and Q-bar (complementary) outputs, providing designers with flexibility in implementing various logic functions.

Key features of the MC14013BCP include:

• Voltage supply range from 3V to 18V, accommodating a wide array of digital systems.
• Static flip-flop operation - retains state indefinitely with clock level either high or low.
• Set-Reset capability - direct inputs override clocked operations, providing immediate state control.
• High noise immunity characteristic of CMOS devices, ensuring stable operation in electrically noisy environments.
• Low power TTL compatibility, making it suitable for interfacing with TTL logic without additional components.

ON Semiconductor's commitment to quality ensures that the MC14013BCP meets stringent standards for reliability and performance. Whether used in educational projects to teach digital logic concepts or implemented in industrial applications for reliable digital storage and control, the MC14013BCP is a dependable choice for engineers and hobbyists alike.

With its combination of high functionality, ease of use, and ON Semiconductor's reputation for durable construction, the MC14013BCP is an essential component for any digital electronics toolkit.
