Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 60V
Current - Average Rectified (Io) (per Diode) 10A
Voltage - Forward (Vf) (Max) @ If 950mV @ 20A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 150μA @ 60V
Operating Temperature - Junction -65°C to 175°C
Mounting SMD (SMT)
Case / Package D2PAK-3
Win Source Part Number 1072570-MBRB2060CTG
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MBRB2060CTG CAD Model

Description

The MBRB2060CTG is a robust and efficient Schottky barrier rectifier designed by ON Semiconductor, a leading manufacturer in the semiconductor industry. This high-performance component is well-suited for a variety of applications, particularly in power supply operations where low forward voltage drop and fast switching are required.

Key Features

  • High Surge Capacity: The MBRB2060CTG is capable of handling high surge currents, making it an ideal choice for applications that experience frequent power surges.
  • Low Power Loss: With its low forward voltage drop, this rectifier ensures minimal power loss, thereby increasing the efficiency of the overall system.
  • High Frequency Operation: Its fast switching capability allows it to operate at higher frequencies without compromising performance, which is crucial for modern, high-speed power circuits.
  • Dual Diode Configuration: The device features a common cathode dual diode configuration, which simplifies the design of parallel or series diode applications.
  • Robust Package: Encased in a D2PAK surface mount package, the MBRB2060CTG offers a compact footprint while providing excellent power handling capabilities.

Applications

The MBRB2060CTG is versatile and can be used in a wide range of applications, including:

  • Switch Mode Power Supplies (SMPS)
  • Power Factor Correction (PFC) circuits
  • Free-Wheeling diodes in converters and motor control circuits
  • DC-DC converters
  • Automotive applications requiring high reliability

Specifications

Some of the key electrical characteristics of the MBRB2060CTG include:

  • Maximum repetitive peak reverse voltage: 60V
  • Average rectified forward current: 20A
  • Non-repetitive peak surge current: 150A
  • Operating junction temperature range: -55°C to 150°C

With its combination of durability, efficiency, and high-performance capabilities, the MBRB2060CTG from ON Semiconductor is an excellent choice for engineers and designers looking to enhance their power management systems.
