Products specifications

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Bi-CMOS
Applications Camera
Output Current 200mA
Supply Voltage - Operating 2.5 V to 6 V
Voltage - Load 2.5 V to 6 V
Temperature Range - Operating -30°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 16-VCT (2.6x2.6)
Win Source Part Number 123584-LV8080LP-TE-L-E
Ultra Librarian 3D Model Ultra Librarian LV8080LP-TE-L-E CAD Model

Description

The ON Semiconductor LV8080LP-TE-L-E is a state-of-the-art motor driver integrated circuit (IC) designed for precision control of small brushed DC motors. This compact, high-efficiency driver is ideal for a wide range of applications, including consumer electronics, office automation equipment, and battery-operated devices.

Key Features

  • Low Voltage Operation: The LV8080LP-TE-L-E operates at a low voltage range, making it suitable for portable and battery-powered applications where power efficiency is critical.
  • Integrated Motor Driver: It integrates a full H-bridge driver for forward and reverse motor control, simplifying circuit design and reducing external component count.
  • Small Package: The IC comes in a compact package, which is perfect for space-constrained applications.
  • Low Saturation Voltage: The device is designed to have a low saturation voltage to minimize power loss and improve efficiency during operation.
  • Thermal Shutdown: It features a thermal shutdown mechanism that protects the IC from overheating, enhancing the reliability and longevity of the application.
  • Absolute Maximum Ratings: The LV8080LP-TE-L-E is built to withstand the rigors of demanding applications with robust absolute maximum ratings.

Applications

The versatility of the LV8080LP-TE-L-E allows it to be used in a variety of applications. It is particularly well-suited for:

  • Portable electronic devices
  • Battery-operated toys
  • Office automation machines such as printers and scanners
  • Small home appliances

Technical Specifications

The LV8080LP-TE-L-E offers a comprehensive set of technical specifications that ensure optimal performance in a multitude of motor driving scenarios. Some of its key specifications include:

  • Operating voltage range tailored for low-power applications
  • Built-in protection features for enhanced safety and reliability
  • High-efficiency operation to extend battery life in portable devices

With its robust feature set, the ON Semiconductor LV8080LP-TE-L-E motor driver IC stands as a top choice for designers looking to create compact, efficient, and reliable motor control solutions.
