FSB50550A

Part No FSB50550A
Manufacturer ON Semiconductor
Catalog Power Drivers - Modules
Description Smart Power Module (SPM®) | MODULE SPM 500V 2A SPM5P
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Type MOSFET
Configuration 3 Phase
Current 2A
Voltage 500V
Voltage - Isolation 1500Vrms
Manufacturer Package 23-PowerDIP Module (0.573", 14.56mm)
Family Part Number FSB50550
Manufacturer Pack Quantity 270
MSL Level 1 (Unlimited)
Win Source Part Number 1175873-FSB50550A
Manufacturer Homepage www.fairchildsemi.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian FSB50550A CAD Model

Description

The FSB50550A from ON Semiconductor is an advanced smart power module (SPM) that integrates power semiconductors, gate drive, and protection circuitry in a compact, thermally efficient package. Designed for high-performance applications, this module is an ideal choice for driving small power motors in a variety of industrial and consumer products.

Key Features:

  • Integrated Design: The FSB50550A combines IGBTs, freewheeling diodes, and gate drivers in a single package, reducing the complexity and footprint of motor drive circuitry.
  • 600V RDS(on) IGBT Technology: This module is built with high-voltage, low-loss IGBTs, ensuring efficient operation and robust performance in demanding conditions.
  • Advanced Protection: It features under-voltage lockout, over-current protection, and thermal shutdown, safeguarding the module and the system it controls against a wide range of fault conditions.
  • Compact Footprint: The FSB50550A's small form factor allows for a reduction in PCB size, making it perfect for applications where space is at a premium.
  • Isolation: The module provides 2500Vrms/min of isolation, ensuring safe operation and protecting sensitive control electronics from high-voltage transients.

Applications:

  • Small motor drives
  • Home appliances
  • Fans and blowers
  • Pumps and compressors
  • DIY power tools

Technical Specifications:

  • Collector-Emitter Voltage (Vces): 600V
  • Collector Current (Ic): 3A
  • Isolation Voltage: 2500Vrms/min
  • Package: Mini-DIP

The FSB50550A by ON Semiconductor is a testament to the company's commitment to providing innovative, high-quality components that streamline the design and enhance the performance of electronic systems. With its integration of multiple functionalities into one package, the FSB50550A offers a reliable and efficient solution for motor control applications.
