Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 75V
Current - Average Rectified (Io) 200mA (DC)
Voltage - Forward (Vf) (Max) @ If 1.25V @ 150mA
Reverse Recovery Time (trr) 6ns
Current - Reverse Leakage @ Vr 1μA @ 75V
Capacitance @ Vr, F 2pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-523
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 010884-BAS16XV2T1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial
Family Name BAS16XV2
Introduction Date October 27, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian BAS16XV2T1G CAD Model

Description

ON Semiconductor BAS16XV2T1G - High-Speed Switching Diode

The BAS16XV2T1G from ON Semiconductor is a high-speed switching diode that epitomizes efficiency and reliability. Designed to meet the needs of a wide variety of electronic applications, this diode is a versatile component for engineers and designers alike.

This diode features a fast switching speed, making it ideal for high-frequency operations. With a reverse recovery time that is optimized for high-speed switch mode applications, the BAS16XV2T1G ensures that systems run smoothly and efficiently, minimizing energy losses and heat generation.

The BAS16XV2T1G boasts a low forward voltage drop, which contributes to its high efficiency. This characteristic is particularly beneficial in portable devices where battery life is paramount, as it helps to conserve power and extend the operational lifespan of the product.

With its SOD-523 package, the BAS16XV2T1G is not only compact but also robust, capable of withstanding mechanical stress and conducive to high-density PCB designs. This small form factor is especially advantageous in space-constrained applications, allowing for more compact and innovative product designs.

The device is characterized by its high surge current capability, which provides a safeguard against unexpected voltage spikes, thus protecting sensitive electronic components. This feature is crucial for products that may be exposed to unstable power supplies or transient environmental conditions.

ON Semiconductor has ensured that the BAS16XV2T1G is compliant with the stringent requirements of the RoHS directive, making it a lead-free and environmentally friendly choice for modern electronic devices. This commitment to sustainability is increasingly important in a world where consumers and regulators demand greener electronic solutions.

In summary, the BAS16XV2T1G is a testament to ON Semiconductor's dedication to producing components that are not only powerful and versatile but also environmentally conscious. Its fast switching speed, low power consumption, and compact size make it an excellent choice for a myriad of applications, including but not limited to signal processing, power management, and protection circuits.
