Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Bulk
Status Obsolete(EOL)
Polarity P-Channel
Voltage - Breakdown (V(BR)GSS) 40V
Current - Drain (Idss) @ Vds (Vgs=0) 2mA @ 15V
Voltage - Cutoff (VGS off) @ Id 1V @ 1μA
Max Input Capacitance 7pF @ 15V
Maximum Power Dissipation 350mW
Temperature Range - Operating -65°C to 135°C (TJ)
Mounting Through Hole
Case / Package TO-92-3
Win Source Part Number 153084-2N5461
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name 2N5461
Introduction Date November 26, 2001
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian 2N5461 CAD Model

Description

ON Semiconductor 2N5461 P-Channel JFET

The ON Semiconductor 2N5461 is a high-performance P-Channel Junction Field Effect Transistor (JFET) that offers excellent characteristics for a wide range of applications. Designed for low-level analog switching and amplifier applications, this JFET is well-suited for audio, instrumentation, and sensor interfacing circuits. The 2N5461 is recognized for its high input impedance and low noise, making it an ideal choice for sensitive audio amplifiers and preamplifiers.

The device is encapsulated in a TO-92 package, which is compact and suitable for through-hole PCB mounting. This makes it easy to integrate into various circuit designs without taking up significant space. The TO-92 package also provides adequate thermal performance for the device's intended applications.

Key features of the 2N5461 include:

  • Low On-Resistance: The transistor offers a low on-state resistance, which results in minimal signal attenuation and power loss, ensuring efficient operation in analog circuits.
  • High Input Impedance: With its high input impedance, the 2N5461 minimizes the loading effect on preceding stages of a circuit, preserving signal integrity and allowing for more accurate signal processing.
  • Low Leakage Current: The device exhibits low leakage current, which is critical for maintaining signal fidelity and reducing power consumption in standby modes.
  • Low Noise: The 2N5461 is characterized by its low noise performance, which is essential for applications that require clean and precise signal amplification.

The 2N5461 operates effectively over a wide range of temperatures, making it reliable in varying environmental conditions. Its P-Channel configuration allows for the design of complementary circuits when paired with an N-Channel JFET, offering designers flexibility in creating balanced designs.

This product from ON Semiconductor is a testament to the company's commitment to providing high-quality components for the electronics industry. Whether you're designing an audio amplifier, a sensitive sensor interface, or a precise analog switch, the 2N5461 is an excellent choice that combines performance, reliability, and versatility.

For detailed specifications and application guidelines, refer to the official datasheet provided by ON Semiconductor. The 2N5461 is available through various distributors and is supported by ON Semiconductor's technical resources to assist designers in their product development journey.
