The ON Semiconductor 2N2904 is a high-quality general-purpose PNP transistor that is widely used in a variety of electronic circuits. This versatile bipolar junction transistor (BJT) is designed for medium power linear and switching applications, making it a reliable choice for designers and engineers.
With its robust construction, the 2N2904 offers excellent performance characteristics that include a high current gain (hFE) and a low saturation voltage, which makes it suitable for amplification and switching tasks. The device can handle continuous collector currents up to 600 mA, which allows it to drive moderate loads in electronic circuits.
Key Features:
- Voltage: Capable of withstanding collector-emitter voltages up to 40V, making it suitable for a range of power applications.
- Current: Continuous collector current of up to 600 mA allows for driving moderate loads.
- Power Dissipation: With a power dissipation of 400 mW, it can handle a fair amount of power without overheating.
- Gain: High current gain (hFE) ensures effective amplification in various circuit designs.
Applications:
- Linear amplification and switching
- Signal processing
- Power regulation circuits
- Driver stages in hi-fi amplifiers and television circuits
The ON Semiconductor 2N2904 is enclosed in a TO-92 package, which is widely used and easy to handle in PCB designs. Its small footprint and lead configuration make it easy to incorporate into a variety of circuit layouts. The transistor's performance and packaging are optimized for commercial, industrial, and military grade applications, ensuring reliability across different operating environments.
Whether you're working on a simple hobby project or a sophisticated industrial design, the ON Semiconductor 2N2904 offers the performance and versatility needed to meet your circuit requirements. Its combination of power handling, gain, and packaging makes it a staple component in the electronics industry.
