XF3M-2115-1B

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	XF3M-2115-1B
Manufacturer	Omron
Catalog	FFC, FPC (FlatFlexible) Connector Assemblies
Description	CONN FFC FPC 21POS 0.5MM R/A
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Flat Flex Type	FFC, FPC
Mounting Type	Surface Mount, Right Angle
Connector/Contact Type	Contacts, Top and Bottom
Number of Positions	21
Pitch	0.020" (0.50mm)
Termination	Solder
FFC, FCB Thickness	0.30mm
Height Above Board	0.079" (2.00mm)
Locking Feature	Rotary Lock, Backlock
Cable End Type	Tapered
Contact Material	Copper Alloy
Contact Finish	Gold
Housing Material	Liquid Crystal Polymer (LCP), Halogen Free
Actuator Material	Liquid Crystal Polymer (LCP), Halogen Free
Features	Solder Retention
Voltage Rating	50V
Temperature Range - Operating	-30°C ~ 85°C
Material Flammability Rating	UL94 V-0
Package	Tape & Reel
Supply and Demand Status	Shortage
Win Source Part Number	1625806-XF3M-2115-1B
