Same model may have multiple batches, images only for reference.
SS-5GL111-FD2 Real Image
Same model may have multiple batches, images only for reference.

SS-5GL111-FD2

Part No SS-5GL111-FD2
Manufacturer Omron
Catalog Snap Action, Limit Switches
Description SWITCH SNAP ACTION SPDT 5A 125V  /  Switch SPDT Through Hole, Right Angle
Datasheet
SS-5GL111-FD2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Limit Switches
Mfr Omron Electronics Inc-EMC Div
Series SS
Package Bulk
Circuit SPDT
Switch Function On-Mom
Current Rating (Amps) 5A (AC)
Voltage Rating - AC 125 V
Actuator Type Lever, Straight
Mounting Type Through Hole, Right Angle
Termination Style PC Pin
Ingress Protection IP40
Operating Force 12gf
Release Force 2.039gf
Differential Travel 0.047" (1.2mm)
Overtravel 0.047" (1.2mm)
Temperature Range - Operating -25°C ~ 85°C
Operating Position 0.345" (8.8mm)
Electrical Life 200,000 Cycles
Mechanical Life 30,000,000 Cycles
Base Product Number SS-5
Other Names SS5GL111FD2
Standard Package 500
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.50.7000
Win Source Part Number 1233550-SS-5GL111-FD2
Ultra Librarian 3D Model Ultra Librarian SS-5GL111-FD2 CAD Model

Description

The Omron SS series limit switch, SS-5GL111-FD2, is a Single Pole Double Throw (SPDT) switch with On-Mom switch function and lever, straight actuator type.

  • Voltage Rating: 125 V AC
  • Current Rating: 5A (AC)
  • Mechanical Life: 30,000,000 cycles
  • Electrical Life: 200,000 cycles
  • Ingress Protection: IP40
  • Temperature Range: -25°C to 85°C
  • Differential Travel: 0.047" (1.2mm)
  • Overtravel: 0.047" (1.2mm)
  • Operating Position: 0.345" (8.8mm)
  • Release Force: 2.039gf
  • Operating Force: 12gf
  • Mounting Type: Through Hole, Right Angle
  • Packaging: Bulk
  • Circuit: SPDT
  • Switch Function: On-Mom
  • Actuator Type: Lever, Straight
