The TJA1055T/CM is a robust, high-speed transceiver from NXP Semiconductors designed to interface between Controller Area Network (CAN) protocol controllers and the physical two-wire CAN bus. This device is specifically tailored to provide a reliable data communication solution for automotive and industrial applications that require efficient data exchange with minimal electromagnetic emissions and high immunity against interferences.

Key Features

• ISO 11898-2:2003 Compliant: Conforms to the latest CAN standards for high-speed data transmission.
• Low Power Mode: Features a very low current standby mode with bus wake-up capability, reducing power consumption when the network is idle.
• Bus Fault Protection: Equipped with extensive fault protection features, including thermal protection, and is capable of withstanding up to ±36V on the CAN bus.
• Transmission Rate: Supports CAN transmission rates up to 1 Megabit per second (Mbps).
• Remote Wake-Up: Allows for remote wake-up of the network through the CAN bus, enhancing network management.

Applications

The TJA1055T/CM is ideal for a wide range of applications in the automotive sector, such as powertrain, chassis, safety, and driver assistance systems. It is also well-suited for industrial automation, medical equipment, and other environments that utilize CAN networks for robust and reliable communication.

Package and Quality

This transceiver is available in a SO14 (Small Outline) package, ensuring compact integration into system designs. It is manufactured by NXP, a trusted leader in automotive semiconductors, ensuring high quality and reliability.

Additional Information

For more detailed technical specifications, application notes, and support documentation, please refer to the official NXP datasheet for the TJA1055T/CM. Designers and engineers can also access NXP's comprehensive support resources, including development tools and reference designs, to facilitate the integration of the TJA1055T/CM into their projects.
