Products specifications

Manufacturer NXP
Win Source Part Number 1239374-PRTR5V0U2F
Manufacturer Homepage www.nxp.com
Family Name PRTR5V0U2F
Introduction Date November 03, 2008
ECCN EAR99
Country of Origin China, Malaysia
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PRTR5V0U2F CAD Model

Description

NXP PRTR5V0U2F Ultra Low Capacitance Double Rail-to-Rail ESD Protection

The NXP PRTR5V0U2F is a state-of-the-art ESD protection device designed to safeguard high-speed data lines from electrostatic discharge damages. This component is part of NXP's portfolio of ESD protection devices, which are engineered to provide robust protection for electronic equipment. The PRTR5V0U2F is particularly suitable for applications that require ultra-low capacitance and minimal signal distortion, making it an ideal choice for USB 2.0, HDMI, LVDS, and other high-speed data interfaces.

Featuring a double rail-to-rail configuration, the PRTR5V0U2F ensures that both positive and negative transients are clamped effectively, providing symmetrical ESD protection for differential data lines. The device comes in a small SOT143B plastic package, which not only saves valuable PCB space but also allows for closer placement to the data lines, thereby enhancing its protective performance.

One of the key specifications of the PRTR5V0U2F is its ultra-low line capacitance of only 0.7 pF. This low capacitance ensures that the signal integrity of high-speed data lines is maintained, preventing any significant impact on signal rise and fall times. Additionally, the device is capable of withstanding ESD discharges up to 8 kV according to the IEC 61000-4-2 standard, offering a high level of protection against common ESD events.

The NXP PRTR5V0U2F also features a very low leakage current, minimizing power consumption when the device is in standby mode. This characteristic is particularly important for battery-powered applications, where power efficiency is crucial. Furthermore, its robust design allows the PRTR5V0U2F to operate over a wide temperature range, ensuring reliable performance under various environmental conditions.

Overall, the NXP PRTR5V0U2F is an excellent choice for designers looking to enhance the ESD robustness of their systems without compromising on signal quality or power efficiency. Its combination of ultra-low capacitance, high ESD protection level, and compact form factor makes it a versatile and reliable solution for a wide range of high-speed data applications.
