NXP PCA9632DP1,118 LED Driver IC

The NXP PCA9632DP1,118 is a highly efficient, 4-channel LED driver designed to manage the requirements of multi-color and white-LED applications. This compact and versatile IC is ideal for a wide range of uses, from enhancing consumer electronics with colorful lighting solutions to providing sophisticated backlighting in automotive and industrial environments.

Key Features

• Four LED Output Channels: The PCA9632DP1,118 supports four LED outputs, allowing for individual control of multiple LEDs, which is perfect for RGB or RGBA LED configurations.
• I²C-Bus Interface: With an I²C-bus interface, the device ensures easy integration into existing designs, providing simplicity in communication and control.
• Output Drive Capability: Each of the four channels can sink up to 25 mA, enabling the driver to handle common LED requirements with ease.
• Programmable Group Blinking: The device supports hardware programmable blink rates and duty cycles, adding dynamic lighting effects without additional software overhead.
• Low Standby Current: The PCA9632DP1,118 is designed for power-sensitive applications, with a low standby current that contributes to overall energy efficiency.
• Internal Oscillator: The built-in oscillator for the PWM controller simplifies design and reduces external component count.
• Software Reset Feature: A software reset function allows for the device to be reset through the I²C-bus, ensuring easy recovery from error states.
• Supply Voltage Range: The device operates on a supply voltage range of 2.3 V to 5.5 V, accommodating various system power supplies.

Applications

The PCA9632DP1,118 is designed for flexible use across a broad spectrum of applications. Its capabilities are particularly well-suited for:

• RGB or RGBA LED driving in consumer electronics
• Backlighting LCD displays in automotive dashboards
• Industrial control indicators
• Keypad backlights for mobile devices
• Status or diagnostic indicators in various electronic systems

With its small footprint, the PCA9632DP1,118 comes in a TSSOP16 package, making it an ideal solution for space-constrained applications. Its robust feature set, including built-in safety features like thermal shutdown and open/short LED detection, ensures reliable and consistent performance, making it a trusted choice for designers and engineers looking to enhance their products with high-quality LED illumination.
