The NX3L2467HR is a high-performance, dual single-pole double-throw analog switch from NXP Semiconductors, designed to deliver exceptional signal switching capabilities for a variety of applications. This advanced switch is an ideal solution for routing analog or digital signals in portable consumer electronics, data communication devices, and computer peripherals.

Key Features

• Low On-Resistance: The device boasts a low on-resistance (Ron) typically around 0.37 Ω at 4.5 V VCC, ensuring minimal signal attenuation and power loss.
• Wide Supply Voltage Range: It operates over a wide supply voltage range from 1.65 V to 5.5 V, making it suitable for interfacing with both low-voltage and standard logic levels.
• High-Speed Switching: Fast switching speeds characterize the NX3L2467HR, with a typical break-before-make time of only 0.5 ns, facilitating rapid signal routing without overlap.
• Low Power Consumption: Its design prioritizes energy efficiency, with a very low quiescent current that significantly reduces power consumption when the switch is in the off state.
• ESD Protection: The device includes robust Electrostatic Discharge (ESD) protection on all pins, safeguarding it against the common risks of handling and circuit integration.

Applications

The versatility of the NX3L2467HR allows it to be used in a wide array of applications, including but not limited to:

• Cellular phones
• PDAs
• Portable media players
• Notebook computers
• Data acquisition systems
• Communication systems

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality products. The NX3L2467HR is manufactured in a lead-free process, compliant with current environmental regulations, and is available in a halogen-free TSSOP14 package. Its reliability is further ensured through rigorous testing protocols adhered to by NXP, guaranteeing performance across its specified temperature range and lifecycle.

For detailed specifications, application notes, and further information, engineers and product designers are encouraged to consult the official NXP datasheets and product guides for the NX3L2467HR.
