Products specifications

Categories Circuit Protection
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5.5V (Max)
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 1pF @ 1MHz
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 6-TSOP
Win Source Part Number 017313-IP4220CZ6,125
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Safety, Communications & Networking, Wireless, Multimedia, Portable Devices, Consumer Electronics
Family Name IP4220CZ6
Introduction Date September 17, 2004
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian IP4220CZ6,125 CAD Model

Description

Product Overview: NXP IP4220CZ6,125

The NXP IP4220CZ6,125 is a highly integrated, low-capacitance ESD protection device designed to safeguard high-speed data lines from electrostatic discharge (ESD) threats. It is a part of NXP's acclaimed ESD protection product line, offering a compact and efficient solution for modern electronic devices where space is at a premium and protection against ESD is crucial for maintaining functionality and reliability.

Key Features

  • Low Clamping Voltage: The device provides a very low clamping voltage, which is essential for protecting sensitive electronics components from the high voltage generated by ESD events.
  • Low Capacitance: With its low capacitance design, the IP4220CZ6,125 ensures that signal integrity is maintained, particularly important for high-speed data lines where any added capacitance can degrade signal quality.
  • Multiple Channel Protection: The device features six protection diodes, which can be used to protect up to three differential pairs or six single lines, making it versatile for various applications.
  • Ultra-small Package: Enclosed in an ultra-small leadless 6-pin package (DFN2020-6 or SOT1118), the IP4220CZ6,125 is optimized for space-constrained applications.
  • High ESD Protection: It offers robust protection against ESD, exceeding the highest level of the IEC61000-4-2 standard, which is ±8 kV contact discharge.

Applications

The NXP IP4220CZ6,125 is suited for a wide range of applications where ESD protection is necessary. It is particularly useful in:

  • USB 2.0 power and data line protection
  • HDMI and DisplayPort interfaces
  • Portable electronics such as smartphones and tablets
  • Digital video interfaces and camera links
  • Other high-speed data interfaces requiring ESD protection

Reliability and Quality

NXP Semiconductors is known for its commitment to quality and reliability, and the IP4220CZ6,125 is no exception. It is manufactured with the highest industry standards in mind, ensuring that it not only protects your electronic devices from transient voltage spikes but also contributes to the overall longevity and durability of the end product.

In conclusion, the NXP IP4220CZ6,125 is an essential component for any designer looking to enhance the ESD resilience of their high-speed data interfaces. Its combination of low capacitance, high protection levels, and compact form factor makes it an excellent choice for safeguarding sensitive electronics.
