Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr NTE
Package Bag
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 1 V @ 3 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 50 ns
Current - Reverse Leakage @ Vr 10 µA @ 100 V
Capacitance @ Vr, F 45pF @ 4V, 1MHz
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Supplier Device Package DO-201AD
Standard Package 1 pcs
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 694224-UF5401
Ultra Librarian 3D Model Ultra Librarian UF5401 CAD Model

Description

The UF5401 is a fast recovery rectifier diode designed for high-speed switching applications.

  • Maximum Reverse Voltage: 100V
  • Average Rectified Current: 3A
  • Forward Voltage Drop: 1V @ 3A
  • Reverse Recovery Time: 50ns
  • Reverse Leakage Current: 10µA @ maximum reverse voltage
  • Capacitance: 45pF @ 4V and 1MHz
  • Package: DO-201AD axial
  • Manufacturer: NTE
  • Status: Active
