1N4934
Same model may have multiple batches, images only for reference.

1N4934

Part No 1N4934
Manufacturer NTE
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 100V 1A DO41 / Diode 100 V 1A Through Hole DO-41
Datasheet
1N4934 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr NTE
Package Bag
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 1 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 150 ns
Current - Reverse Leakage @ Vr 5 µA @ 100 V
Capacitance @ Vr, F 12pF @ 4V, 1MHz
Mounting Type Through Hole
Package / Case DO-204AL, DO-41, Axial
Supplier Device Package DO-41
Operating Temperature - Junction -50°C ~ 150°C
Standard Package 1 pcs
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 850430-1N4934
Ultra Librarian 3D Model Ultra Librarian 1N4934 CAD Model

Description

The 850430-1N4934 is a single rectifier diode used in various electronic applications. It falls under the Discrete Semiconductor Products - Diodes - Rectifiers category.

  • Category: Discrete Semiconductor Products - Diodes - Rectifiers
  • Recovery Speed: Fast (<500ns)
  • Current Handling: >200mA
  • Vr (Max): 100 V
  • Io: 1A
  • Vf: 1.2 V @ 1 A
  • trr: 150 ns
  • Ir: 5 μA @ 100 V
  • Mounting: Through-Hole
  • Package: DO-204AL, DO-41, Axial
  • Operating Temperature: -50°C to 150°C
  • Manufacturer: NTE
  • Status: Active
