JS0304PP4-S NKK Switches – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

JS0304PP4-S

Part No JS0304PP4-S
Manufacturer NKK Switches
Catalog DIP Switches
Description SWITCH PIANO DIP SPST 0.025A 24V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Circuit SPST
Number of Positions 4
Current Rating (Amps) 25mA
Voltage Rating 24VDC
Actuator Type Piano
Actuator Level Raised
Contact Material Phosphor Bronze
Contact Finish Gold
Height Above Board 0.362" (9.20mm)
Mounting Type Through Hole, Right Angle
Termination Style PC Pin
Pitch 0.100" (2.54mm), Full
Washable No
Temperature Range - Operating -25°C ~ 70°C
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1553096-JS0304PP4-S
Ultra Librarian 3D Model Ultra Librarian JS0304PP4-S CAD Model
