NJM3775E3-TE2 NJR Corporation/NJRC
Same model may have multiple batches, images only for reference.

NJM3775E3-TE2

Part No NJM3775E3-TE2
Manufacturer Nisshinbo Micro Devices Inc.
Catalog PMIC - Motor Drivers, Controllers
Description IC STEPPER MOTOR DVR DUAL 24EMP
Datasheet
NJM3775E3-TE2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Motor Drivers, Controllers
Mfr Nisshinbo Micro Devices Inc.
Package Tape & Reel
Product Status Obsolete
Motor Type - Stepper Bipolar
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (4)
Interface Parallel
Technology Bipolar
Step Resolution 1, 1/2
Applications General Purpose
Current - Output 750mA
Voltage - Supply 4.75V ~ 5.25V
Voltage - Load 10V ~ 40V
Temperature Range - Operating -20°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 24-SOIC (0.295", 7.50mm Width)
Supplier Device Package 24-SOP
Base Product Number NJM3775
Standard Package 1,500 pcs
ECCN OBSOLETE
Win Source Part Number 255484-NJM3775E3-TE2
Ultra Librarian 3D Model Ultra Librarian NJM3775E3-TE2 CAD Model

Description

The NJM3775E3-TE2 is a motor driver IC designed for general purpose applications. It is a surface mount device packaged in a 24-SOIC package, with a width of 7.50mm. The NJM3775E3-TE2 is part of Nisshinbo Micro Devices Inc.'s NJM3775 series.

  • Configuration: Half bridge
  • Current Output: 750mA
  • Motor Type: Bipolar stepper motors
  • Voltage Load Range: 10V to 40V
  • Interface: Parallel
  • Step Resolutions: 1 and 1/2
  • Package: 1,500 pcs
  • Product Status: Obsolete
  • ECCN: OBSOLETE
  • Supplier Device Package: 24-SOP
  • Temperature Range: -20°C to 150°C (TJ)
