Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Capacitors>Electric Double Layer Capacitors (EDLC), Supercapacitors
Mfr Nichicon
Series EVerCAP® JUW
Package Bulk
Capacitance 6.8 F
Tolerance ±20%
Voltage - Rated 2.7 V
ESR (Equivalent Series Resistance) 800mOhm @ 1kHz
Lifetime @ Temp. 1000 Hrs @ 70°C
Termination PC Pins
Mounting Type Through Hole
Package / Case Radial, Can
Lead Spacing 0.197" (5.00mm)
Dimension 0.492" Dia (12.50mm)
Height - Seated (Max) 0.866" (22.00mm)
Temperature Range - Operating -25°C ~ 70°C
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Other Names 493-4334
Standard Package 100
Win Source Part Number 1097704-JUWT1685MHD
Ultra Librarian 3D Model Ultra Librarian JUWT1685MHD CAD Model

Description

The JUWT1685MHD is an electric double layer capacitor (EDLC) or supercapacitor manufactured by Nichicon.

  • Type: Radial, can type capacitor
  • Capacitance: 6.8 F
  • Voltage Rating: 2.7 V
  • ESR: 800mOhm @ 1kHz
  • Mounting Type: Through-hole
  • Lead Spacing: 0.197" (5.00mm)
  • Height Seated: 0.866" (22.00mm)
  • Diameter: 0.492" (12.50mm)
  • Standard Package: 100
  • Lifetime: 1000 Hrs @ 70°C
  • Series: EVerCAP® JUW series
