The NPIM52B2R2MTRF is a power inductor manufactured by NIC-Components Corp. It is a shielded inductor designed for DC-DC converter applications. Its compact size and robust construction make it suitable for use in various power management circuits.

Applications:

• DC-DC Converters
• Point-of-Load (POL) regulators
• Buck converters
• Boost converters
• Power supplies for portable devices

Features:

• Shielded construction for low EMI
• Compact size: 5.0 x 5.0 x 2.0 mm
• High saturation current
• Surface mount design
• Operating temperature range: -40°C to +125°C
• Ferrite core material

Benefits:

• Reduced electromagnetic interference (EMI) allows for use in sensitive electronic circuits without causing noise issues.
• Small footprint enables miniaturization of electronic devices, saving space on the PCB.
• High saturation current ensures stable performance even under peak current conditions, preventing inductor saturation.
• Easy to assemble using standard surface mount technology (SMT) processes, reducing manufacturing time and cost.
• Reliable operation across a wide temperature range makes it suitable for various environmental conditions.

Technical Specifications:

Inductance: 2.2 µH
Tolerance: ±20%
Saturation Current: 1.7 A
DC Resistance (DCR): 115 mΩ (typical)
Self-Resonant Frequency (SRF): 90 MHz (typical)
Operating Temperature: -40°C to +125°C
Core Material: Ferrite
Termination: Tin plating

The NPIM52B2R2MTRF power inductor offers a compact solution for power management applications. Its shielded construction minimizes EMI, ensuring cleaner power delivery. The high saturation current and low DC resistance contribute to efficient power conversion, while its small size makes it ideal for portable and space-constrained devices. The inductor's wide operating temperature range further enhances its suitability for use in diverse environments.
