NACZ101M50V8X10.5TR13F Real Image
Same model may have multiple batches, images only for reference.

NACZ101M50V8X10.5TR13F

Part No NACZ101M50V8X10.5TR13F
Manufacturer NIC-Components Corp.
Catalog Aluminum Capacitors
Description NACZ Series 100 uF 50 V 20 % SMT V- Chip Aluminum Electrolytic Capacitor
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Capacitance 100 µF
Diameter 8 mm
ESR (Equivalent Series Resistance) 400 mΩ
Height 10.5 mm
Impedance 400 mΩ
Lead Diameter 1 mm
Lead Free Yes
Lead Pitch 3.2 mm
Leakage Current 50.5 µA
Life (Hours) 2000 hours
Maximum Operating Temperature 105 °C
Min Operating Temperature -55 °C
Mount Surface Mount
Radiation Hardening No
Ripple Current 300 mA
RoHS Compliant
Schedule B 8532220020, 8532220020
Termination SMD/SMT
Tolerance 20 %
Voltage 50 V
Voltage Rating 50 V
Win Source Part Number 1074018-NACZ101M50V8X10.5TR13F
Categories Aluminum Capacitors
Manufacturer NIC-Components Corp.
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian NACZ101M50V8X10.5TR13F CAD Model

Description

The NACZ101M50V8X10.5TR13F from NIC-Components Corp. is a surface mount aluminum capacitor.

  • Capacitance: 100 µF
  • Voltage Rating: 50 V
  • Tolerance: 20%
  • Impedance: 400 mΩ
  • ESR: 400 mΩ
  • Ripple Current: 300 mA
  • Height: 10.5 mm
  • Diameter: 8 mm
  • Maximum Operating Temperature: 105 °C
  • Minimum Operating Temperature: -55 °C
  • RoHS Compliant: Yes
  • Lead-Free: Yes
  • Supply: shortage
  • Popularity: low
