PMEG3020BEP,115 Nexperia USA Inc. PMEG3020BEP,115 label picture
Same model may have multiple batches, images only for reference.
PMEG3020BEP,115 Nexperia USA Inc. PMEG3020BEP,115 label picture
PMEG3020BEP,115 Nexperia USA Inc. PMEG3020BEP,115 label picture
Same model may have multiple batches, images only for reference.

PMEG3020BEP,115

Part No PMEG3020BEP,115
Manufacturer Nexperia USA Inc.
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 30V 2A SOD128
Datasheet
PMEG3020BEP,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 450mV @ 2A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 100μA @ 30V
Capacitance @ Vr, F 340pF @ 1V, 1MHz
Mounting SMD (SMT)
Case / Package CFP5
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 1089595-PMEG3020BEP,115
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PMEG3020BEP,115 CAD Model

Description

The Nexperia USA Inc. PMEG3020BEP,115 is a Schottky type electronic component that is part of the discrete semiconductor products category.

  • Device Status: currently active
  • Package: CFP5 package
  • Mounting: surface mount device
  • Maximum Reverse Voltage: 30V
  • Average Rectified Current: 2A
  • Forward Voltage: 450mV @ 2A
  • Reverse Leakage Current: 100μA @ 30V
  • Capacitance: 340pF @ 1V and 1MHz
  • Junction Temperature: 150°C
  • Supply and Demand Constraints: none
